UV Laser Marking Machine

Product Model | -

Product Description

This advanced UV laser marking machine features a 720-degree rotating laser head, perfectly suited for various automated production environments. Its high-precision beam control enables intricate pattern marking on high-density materials, ensuring exceptional product aesthetics and quality.

The system is equipped with an intelligent touch screen control interface powered by a high-performance core chip, ensuring stable operation, user-friendly functionality, and minimal risk of malfunction. Achieving marking speeds of up to 12,000mm/s, it excels in efficiently handling complex patterns with precision.

Designed for seamless integration, the device includes a high-transparency coated field lens that expands the marking area. Additionally, it supports traceability systems, enhancing product safety and enabling accurate tracking, making it an ideal choice for a wide range of industrial marking and tracking applications.

Product Specification

Performance Data

Power: 3W, 5W, 10W, depending on the selected model
Laser Wavelength: 355nm
Marking Speed: ≤12000mm/s
Marking Method: High-precision two-dimensional scanning
Marking Range: Standard 110mm×110mm, optional up to 600mm×600mm
Production Line Speed: 0~189m/min (depending on material and content)
Language Support: English, Chinese, Korean, Russian, German, Arabic, etc.
Barcode/QR Code Support: CODE39, CODE128, CODE126, QR, Z-Code, DM, Visual code, etc.

Hardware Specifications

Casing Material: Anodized aluminum
Main Controller: 10.1-inch external controller
Cooling System: Water-cooled
Positioning Method: Red light positioning and infrared focusing
Reflector Size: Standard 8.5mm
Power Supply: 220V
Maximum Power Consumption: ≤500W (water-cooled ≤800W)
Net Weight: 14kg
Interface: USB 2.0 / Photonic Trigger / Synchronizer

Software Specifications

Operating System: Linux P9
Supported File Format: PLT
Marking Types: Dot matrix and vector
