Handheld Laser Marking Machine - Advanced Model (Battery Version)

Product Model｜ LD20i-BIII

Product Introduction

Engineered for lightweight portability and industrial-grade stability, this device delivers high-resolution marking on materials such as metal, hard plastic, and glass. It supports diverse content formats, including Chinese, English, barcodes, QR codes, and logos.

Product Description

This advanced handheld laser printer is designed to meet a wide range of industrial marking requirements, ideal for applications in food packaging, electronic components, asset tracking, and anti-counterfeiting measures. It offers flexible marking ranges of 50x50mm and 100x100mm and is powered by a self-developed operating system with an intuitive 5-inch touchscreen interface for seamless operation.

The device features an intelligent red light positioning system for precise marking and supports multiple file formats, such as PLT, BMP, and PNG, with easy USB file import. Equipped with a durable 6 Ah battery, it is optimized for mobile operations, ensuring reliable performance and enhanced production efficiency in dynamic environments.

Product Specification

Performance Data

Laser Type: Fiber Laser Generator
Output Power: ≥20W
Laser Wavelength: 1064nm
Marking Speed: ≤7000mm/s
Maximum Pulse Energy: 0.67mJ
Frequency Adjustable Range: 27-60 kHz

Hardware Specifications

Material: Engineering Plastic
Reflector Size: 10mm
Marking Range: 50x50mm or 100x100mm (optional)
Battery Capacity: 6 Ah
Maximum Power Consumption: ≤150W
Machine Net Weight: 4kg
Control Box Dimensions: 339mm x 160mm x 273mm
Suitable Temperature: 5-40℃
Environment Relative Humidity: ≤85%RH (no condensation)

Software Specifications

Operating System: P9
Supported Marking Content: Text, LOGO, Barcodes, QR codes
Supported Fonts: Simplified and Traditional Chinese, English, Korean, Russian, Arabic numerals, etc.
Supported Image Formats: BMP, PNG, JPG, JPEG, PLT, GIF, PBM
Barcode/QR Code Formats: CODE39, CODE128, EAN13, PDF417, QR, AZTEC, etc.
File Import Method: USB
