UV LED Lamp 9LH5656 – Uniform High-Power Curing Solution

Product Model｜ 9LH5656

Product Introduction

Designed for 8D printheads, this 500W UV LED lamp ensures consistent curing with a square coverage of 56mm × 56mm, tailored for demanding industrial environments requiring uniform curing.

Product Description

The 9LH5656 UV LED lamp delivers high-intensity curing performance and is compatible with the 8D printhead, providing exceptional reliability for industrial applications. Its adjustable curing strength ensures precise curing tailored to different substrates and production requirements. The compact design and air-cooled heat dissipation allow seamless integration into various production environments, ensuring consistent, high-quality results.

Product Specification

Performance Data

Curing Power: 500W
UV Light Irradiation Length: 56mm
UV Light Irradiation Height: 56mm
Wavelength: 395nm
Peak Irradiance: 12W/cm²

Hardware Specifications

Lamp Dimensions: 135 × 90 × 80mm
Operating Temperature: 15°C to 40°C (59°F to 104°F)
Storage Temperature: 5°C to 45°C (41°F to 113°F)
Certifications: CE, FCC

The 9LH5656 UV LED lamp is an ideal solution for high-demand industrial printing environments, offering flexibility, durability, and top-tier curing performance.
